Model |
GS-3065 |
GS-3065D |
|
|
name |
15 all in one touch pos |
||
|
color |
Black |
||
|
optoinal item |
Card reader &consume display |
||
|
motherboard |
|
||
|
motherboard |
D2500 |
SNE-C1037K |
|
|
cpu |
Intel® Atom D2500 Dual core 1.8GHZ |
Intel Celeron 1037u 1.8GHz |
|
|
chipset |
Intel NM10 |
Intel c1037+NM70 |
|
|
memory |
DDRIII 2G or 4G |
DDRIII 2G or 4G |
|
|
storage device |
64G SSD or 500G SATA |
64G SSD or 500G SATA |
|
|
display |
|
||
|
LCD panel |
15' sharp TFT LCD |
15' sharp TFT LCD |
12' screen LCD |
|
brightness |
250cd /㎡ |
||
|
resolution |
1024*768(max) |
||
|
touch panel |
5 wire R touch panle made in TW |
--- |
|
|
view angle |
R/L：140 U/D ： 130 |
||
|
front I/O |
2*USB(2.0) 1*power button |
||
|
back I/O |
PS/2 mouse *1 PS/2 keyboard*1 |
||
|
COM1 port *1(built in) expand COM2 |
|||
|
LPT print port *1 |
|||
|
VGAout(15Pin D-sub)*1,connect the 2nd display monitor |
|||
|
RJ－45 lan port*1 RTL8111C 10/100/1000M lan card |
|||
|
USB（2.0）*4 |
|||
|
audio out *1 |
|||
|
Mic*1 |
|||
|
DC in*1 |
|||
|
operation temperature |
0 ℃ to 40℃ |
||
|
storage temperature |
-20℃ to 60℃ |
||
|
power source |
DC 12V input |
||
|
Gross Weigh |
KG |
||
|
Net Weigh |
KG |
||
|
Dimension (W*D*H) |
435*375*525(mm) |
||
|
Power Saving |
70W(max) |
||
|
Safety & EMI |
CCC / FCC / CB / CE / EMC |
||
|
operation OS |
Windows XP Professional, Windows XP Embedded, Windows7 |
||
